Four Tap Jockey Box Builder - Stainless Steel Cooler
The main difference with this jockey box cooler set up compared to our Aliminium cold plate is that this particular set up requires a constantĀ ice slurry. That means not just ice poured on, you need to make an ice water slurry. To help you get a fast slurry, we would suggest pouring in cold water on top of your 5kg ice bag. Adding a few handfuls of kosher salt will speed up that process (just remember to rinse after use).
This kit comes with:
1 x KL36047 Four Tap SS Jockey Box Starter Kit
1 x KL13178 Punched Counter Top Drip Tray - 50cm x 17xcm x 1.5cm
4 x KL06903 duotight - 8mm (5/16ā) Female x 5/8ā Female Thread. For the back of the cooler.
1 x KL06231 EVABarrier 5mm x 8mm Double Wall EVA (12meter Length in Bag)
Tapping Options with Low Profile Short Ball Handle (with or without auto close springs):
4 x KL15523 NukaTap FC - Flow Control Gen2
4 x KL15509 NukaTap SSĀ
4 x KL17978 NukaTap SS - Stealth Bomber Black (Gen2)
4 x KL26482 NukaTap SS - Punisher Edition
Kegging Coupler Options:
4 x KL20749 duotight Liquid Disconnect 8mm (Black/Yellow)
4 x KL21418 Flow Control duotight Liquid Disconnect 8mm (Black/Yellow)
4 x KL43250Ā A-Type Keg Coupler All-SS with 8mm duotight Push-Fit
4 x KL43267Ā D-Type Keg Coupler All-SS with 8mm duotight Push-Fit
Please note: This kit does not come with a gas bottle or regulator.
We would recommend either aĀ
1 x KL01489 2.6kg CO2 Cylinder OR a KL01496 6.0kg CO2 Cylinder
1 x KL07429 Type 30 (CO2) MK4 Regulator
3 x KL02387 8mm duotight equal tee splitter (to split the gas line into four)
Using left over gas line from the kit in 5mm ID
Refer to the KegLand Digital Carbonation Chart for level of pressure required to maintain carbonation with the kegs you are dispensing. It is important to note the ambient temperatures when dispensing. e.g. on a 22Ā°C day, with a standard Lager / Pale Ale we'd dispense at 30psi (2.4 CO2 Volumes).
External Dimensions:
590mm wide (including handles)
460mm deep (including latch system and 5/8" Shanks front and back [not including taps])
410mm high
Internal Dimensions:
480mm wide
280mm deep
350mm high (there is a slight recess of 20mm at the top to fit larger kegs/bottles.
